Ingersoll Rand product
Grinders
- Available in straight, extended or 90-degree angle head configurations,
- Multiple speed capacities with options of various attachments for increased productivity
Product Overview
Created for production and non-production industrial applications and for heavy material removal, the grinder line from Ingersoll Rand delivers high performance at an affordable price. The tools feature best-in-class vibration dampening technologies, patented integral guards, and self-locking, spring-loaded throttle levers that prevent accidental operation.
- Choice of angle, pencil or die grinders
- Covers guard sizes from 3" to 9"
- Max free speed up to 35000 RPM
Product resources
Technical specifications
| Series | Configuration | Max free speed RPM | Rated power hp | Guard size in | Output | Weight kg |
|---|---|---|---|---|---|---|
| M2 Type 1 | Extended Straight | 18000 | 1 | 3" & 4" | 3/8" | 1.48 |
| G1 Type 1 | Angle & Straight | 25000 | 0.4 | 3" | 3/8" | 0.6 |
| 77 Pro Type 1 | Extended Straight | 12000 | 1.5 | 3" & 4" | 3/8" & 1/2" | 2.95 |
| 88 Pro Type 1 | Extended Straight | 6000 | 2 | - | 5/8" | 5.1 |
| 99 Pro Type 1 | Extended Straight | 6000 | 3 | 8" | 5/8" | 6.7 |
| G3 Type 1 | Extended Straight | 18000 | 1 | 3" & 4" | 3/8" | 2.04 |
| 61 Pro Type 1 | Extended Straight | 15000 | 1.33 | 3" & 4" | 3/8" | 2.2 |
| 301B & 307B | Angle & Straight | 28000 | 0.25 | - | 1/4" & 6mm | 0.46 |
| 302B & 308B | Straight | 25000 | 0.33 | - | 1/4" & 6mm | 0.58 |
| 61 Pro Cone & Plug | Extended Straight | 15000 | 1.33 | 4" | 3/8" | 1.9 |
| 61 Pro Die | Extended Straight | 15000 | 1.33 | - | 1/4" | 1.9 |
| 77 Pro Angle | Extended Angle | 7500 | 1.5 | 7" & 9" | 5/8" | 4.1 |
| 77 Pro Cone & Plug | Extended Straight | 12000 | 1.5 | 4" | 5/8" | 2.7 |
| 88 Pro Vertical | Vertical | 8500 | 2.2 | 7" & 9" | 5/8" | 4.1 |
| 99 Vertical | Vertical | 8500 | 3 | 7" & 9" | 5/8" | 5.1 |
| Max Angle | Angle | 12000 | 0.88 | 4.5" & 5" | M14 | 1.5 |
| M2 Angle | Angle & Extended Angle | 14500 | 1 | 4" & 5" | 3/8", 5/8" & M14 | 2.07 |
| G1 Angle | Angle | 20000 | 0.4 | 3" | 3/8" | 0.6 |
| G3 Angle | Angle | 12000 | 1 | 4.5" - 6" | M14 | 2.32 |
| G1 Die | Angle & Extended Straight | 35000 | 0.4 | - | 1/4" & 6mm | 0.6 |
| Max Die | Straight | 25000 | 0.4 | - | 1/4" & 6mm | 0.64 |
| M2 Die | Angle & Straight | 25000 | 1 | - | 1/4" & 6mm | 1.62 |
| Revolution Die | Angle, Straight & Extended Straight | 35000 | 0.4 | - | 1/4" & 6mm | 0.62 |
| G3 Die | Angle, Straight & Extended Straight | 18000 | 1 | - | 6mm | 1.7 |
| LA Die | - | 25000 | 0.56 | - | 1/4" & 6mm | 0.54 |
| LA Angle | Angle | 12000 | 0.67 | 4.5" & 5" | 3/8" | 1.7 |
| VT45 Turbine | Angle | 8500 | 6.12 | 7" & 9" | M14 | 4.3 |
| VT26 Turbine | - | 12000 | 3.48 | 5" & 7" | M14 | 2.8 |
