MB Range

Metric Hexagon AF Size Reducer Bushes

Product Overview

To reduce the female hexagon AF size of the TWH-NRH metric ratchet heads, these Hi-Force hexagon reducer bushes offer an easy and economical solution. Just select your outside AF size (i.e ratchet head AF size) and the required inside AF size to determine the model number. Please note that wall thickness (specified below as ‘W’ dimension) must be added to the minimum radius dimension of your ratchet head when using a reducer bush.

Product resources

MB Catalogue Page

Outside AF Size	Inside AF Size	For TWH27NRH		For TWH54NRH		For TWH120NRH		For TWH210NRH		For TWH430NRH
Outside AF Size	Inside AF Size	Model number	W mm	Model number	W mm	Model number	W mm	Model number	W mm	Model number	W mm
30	24	MB27-30-24	3.0
32	24	MB27-32-24	3.0
32	27	MB27-32-27	3.0
36	30	MB27-36-30	3.0	MB54-36-30	3.0
41	36	MB27-41-36	2.5	MB54-41-36	2.5
46	36	MB27-46-36	5.0	MB54-46-36	5.0
46	41	MB27-46-41	2.5	MB54-46-41	2.5
50	41	MB27-50-41	4.5	MB54-50-41	4.5
50	46	MB27-50-46	2.0	MB54-50-46	2.0
55	41	MB27-55-41	7.0	MB54-55-41	7.0
55	46	MB27-55-46	4.5	MB54-55-46	4.5
55	50	MB27-55-50	2.5	MB54-55-50	2.5	MB120-55-50	2.5
60	46	MB27-60-46	7.0	MB54-60-46	7.0	not available	-
60	50	MB27-60-50	5.0	MB54-60-50	5.0	MB120-60-50	5.0
60	55	MB27-60-55	2.5	MB54-60-55	2.5	MB120-60-55	2.5
65	50			MB54-65-50	7.5	MB120-65-50	7.5
65	55			MB54-65-55	5.0	MB120-65-55	5.0
65	60			MB54-65-60	2.5	MB120-65-60	2.5
70	55			MB54-70-55	7.5	MB120-70-55	7.5
70	60			MB54-70-60	5.0	MB120-70-60	5.0
70	65			MB54-70-65	2.5	MB120-70-65	2.5
75	60			MB54-75-60	7.5	MB120-75-60	7.5
75	65			MB54-75-65	5.0	MB120-75-65	5.0
75	70			MB54-75-70	2.5	MB120-75-70	2.5	MB210-75-70	2.5
80	65			MB54-80-65	7.5	MB120-80-65	7.5	not available	-
80	70			MB54-80-70	5.0	MB120-80-70	5.0	MB210-80-70	5.0
80	75			MB54-80-75	2.5	MB120-80-75	2.5	MB210-80-75	2.5
85	70					MB120-85-70	7.5	MB210-85-70	7.5
85	75					MB120-85-75	5.0	MB210-85-75	5.0
85	80					MB120-85-80	2.5	MB210-85-80	2.5	MB430-85-80	2.5
90	75					MB120-90-75	7.5	MB210-90-75	7.5	not available	-
90	80					MB120-90-80	5.0	MB210-90-80	5.0	MB430-90-80	5.0
90	85					MB120-90-85	2.5	MB210-90-85	2.5	MB430-90-85	2.5
95	80					MB120-95-80	7.5	MB210-95-80	7.5	MB430-95-80	7.5
95	85					MB120-95-85	5.0	MB210-95-85	5.0	MB430-95-85	5.0
95	90					MB120-95-90	2.5	MB210-95-90	2.5	MB430-95-90	2.5
100	85					MB120-100-85	7.5	MB210-100-85	7.5	MB430-100-85	7.5
100	90					MB120-100-90	5.0	MB210-100-90	5.0	MB430-100-90	5.0
100	95					MB120-100-95	2.5	MB210-100-95	2.5	MB430-100-95	2.5
105	90							MB210-105-90	7.5	MB430-105-90	7.5
105	95							MB210-105-95	5.0	MB430-105-95	5.0
105	100							MB210-105-100	2.5	MB430-105-100	2.5
110	95							MB210-110-95	7.5	MB430-110-95	7.5
110	100							MB210-110-100	5.0	MB430-110-100	5.0
110	105							MB210-110-105	2.5	MB430-110-105	2.5
115	100							MB210-115-100	7.5	MB430-115-100	7.5
115	105							MB210-115-105	5.0	MB430-115-105	5.0
115	110							MB210-115-110	2.5	MB430-115-110	2.5
130	105									MB430-130-105	12.5
130	110									MB430-130-110	10.0
130	115									MB430-130-115	7.5
145	110									MB430-145-110	17.5
145	115									MB430-145-115	15.0
145	130									MB430-145-130	7.5
