Size		Fitting to model	Capacity (kN)	Weight (kg)
1 Wheel Flange	2 Wheel Flanges			A	B
SF 125S-A	SF 125S-B	SF	20	14.5	14.9
SF 150S-A	SF 150S-B	SF	20	17.2	17.7
SF 175S-A	SF 175S-B	SF	20	21.9	22.5
SF 200S-A	SF 200S-B	SF	20	27.3	28.0

Size		Fitting to model	Capacity (kN)	Weight (kg)
1 Wheel Flange	2 Wheel Flanges			A	B
SF 150S-A/P	SF 150S-B/P	SF	40	17.4	17.9
SF 175S-A/P	SF 175S-B/P	SF	40	22.1	22.7
SF 200S-A/P	SF 200S-B/P	SF	50	27.5	28.2
SF 225S-A/P	SF 225S-B/P	SF	50	33.7	34.5
SF 250S-A/P	SF 250S-B/P	SF	65	42.9	43.7

Dimensions (mm)

Model SF-S-A(B)
Size		a	b	c	∅d1	∅d2	∅e	f	g	h	j	k	m	X Max
1 Wheel Flange	2 Wheel Flanges
SF 125 S-A	SF 125 S-B	220	150	190	125	150	14	115	15	180	80	120	67.5	55
SF 150 S-A	SF 150 S-B	220	150	190	150	175	14	115	15	210	80	120	67.5	55
SF 175 S-A	SF 175 S-B	220	150	190	175	200	14	115	15	235	80	120	67.5	55
SF 200 S-A	SF 200 S-B	220	150	190	200	225	14	115	15	260	80	120	67.5	55

Model SF-S-A(B)/P
Size		a	b	c	∅d1	∅d2	∅e	f	g	h	j	k	m	X Max
1 Wheel Flange	2 Wheel Flanges
SF 150 S-A/P	SF 150 S-B/P	220	170	180	150	175	18	130	20	195	80	130	67.5	55
SF 175 S-A/P	SF 175 S-B/P	220	170	180	175	200	18	130	20	220	80	130	67.5	55
SF 200 S-A/P	SF 200 S-B/P	220	170	180	200	225	18	130	20	245	80	130	67.5	55
SF 225 S-A/P	SF 225 S-B/P	220	170	180	225	275	18	130	20	285	80	130	67.5	55
SF 250 S-A/P	SF 250 S-B/P	270	170	180	200	300	18	130	20	310	80	130	67.5	55
